Trek Speed Concept TT Riser Kit

Fine-tune the stack, angle and reach of your Trek Speed Concept Mono cockpit (Gen 1 & Gen 2) with separately selectable Dabrace™ components for its single-tower, flat-handlebar setup. Choose kevlar polymer flat risers from 10mm to 60mm, a fixed 15° angle spacer, an adjustable 0–32° angle spacer or a CNC aluminium reach extender with a 0–60mm adjustment range. Select M5 or M6 to match your installed cockpit mounting hardware, rather than choosing by the frame name alone.

How to Order Your Setup

First select the M5 or M6 mounting option that matches your cockpit, then choose the component you need and click "Add to Cart". Repeat for each additional component.

Flat Stack Risers: Choose 10mm, 20mm, 30mm, 40mm, 50mm or 60mm.
Fixed 15° Angle Spacer: Select the fixed 15° option separately.
Adjustable 0–32° Angle Spacer: Available in two options: with a riser set (10 + 20 + 30mm) or without risers. View Adjustable Angle Spacer Details →
Reach Extender: Select the CNC aluminium option with a 0–60mm adjustment range separately.
Additional Screws: Extra sets of two M5 or two M6 screws are listed as separate purchase options. Match the screw set to your installed hardware.
BTA Mount: Sold separately through the linked BTA page. It is not included with the risers, angle spacers or reach extender.

Technical Specifications

Cockpit Compatibility	Trek Speed Concept cockpit, matching the installed mounting configuration
Setup Configuration	Single tower / flat handlebar setup
Mounting Options	M5 or M6, selected to match your cockpit
Flat Risers Material	Kevlar polymer
Available Heights	10mm, 20mm, 30mm, 40mm, 50mm, 60mm
Flat Risers Finish	Black matte
Fixed 15° Angle Spacer	Fixed 15°, sold separately
Fixed Angle Spacer Material	Kevlar polymer
Adjustable 0–32° Angle Spacer	Adjustable 0–32°, sold separately. Available with a riser set (10 + 20 + 30mm) or without risers. View Details
Adjustable Angle Spacer Material & Finish	CNC-machined 7075 aluminium / Black anodized
Reach Extender	0–60mm adjustment range, sold separately
Reach Extender Material & Finish	CNC-machined 7075 aluminium / Black anodized
BTA Mount Material	7075 aluminium core with kevlar polymer body
BTA Mount	Sold separately. Match the mounting option to your setup: View Details

Frequently Asked Questions

Q: Should I choose M5 or M6?
A: Match the mounting option to the hardware on your installed cockpit. The bike frame name alone does not confirm the screw size.

Q: Are all adjustment components included together?
A: No. Flat risers, the fixed 15° angle spacer, the adjustable 0–32° angle spacer and the 0–60mm reach extender are separate purchase options. Add each required component individually. The adjustable angle spacer is also available with a 10 + 20 + 30mm riser set.

Q: Is the reach extender a fixed +60mm option?
A: No. This Trek Speed Concept option has a 0–60mm adjustment range.

Q: Is the BTA mount included?
A: No. It is sold separately through the linked BTA page. Check its mounting option against your setup before ordering.
